100KW Electron Tube Triode FD-911S High power triode

FOB Reference Price:Get Latest Price
4 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Liaoning, China (Mainland)
Brand Name:
HUAGUANG
Model Number:
FD-911S
Type:
Triode Transistor
Package Type:
Surface Mount
weight:
16.5kgs
SupplyAbility
SupplyAbility:
100 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Wooden box dimensions is 86*86*88cm/4pcs
GW is 140KGS/box
Port
Dalian port,Tianjin port , Beijing airport
Lead Time :
Within 2 days once the payment is confirmed



 High power triode Triode FD-911S is a  glass triodes,  their anodes cooled by water, and their maximum anode dissipation powers is 80kW; when at a frequency not higher than 26MHz, their output powers may attain to 100kW. They are mainly applied in industrial high-frequency heating equipments for oscillations or in radio equipments for amplifications.



Glass triode (30-600KW)

Type

FD-911S

Equivalent on abroad



Output power(KW)

100

Cathode

Cathode materials

Thoriated

Tungsten

Voltage(V)

12

Current(A)

210

Main electric parameters

Amplification factor

33

Inter-electrode Capacitances (PF)

(Cathode earthed)



Filament-Grid

100

Filament-Anode

2

Anode-Grid

77

Maximum

Maximum anode dissipation (KW)

80

Maximum grid dissipation (W)

2.6

Maximum anode DC voltage (KV)

15

Maximum frequency (MHz)

26

Cooling

S

Weight (kg)

16.5

Additional: The information here may be modified with the products variation.

Cooling: F--Forced air cooling  S--Water cooling  Z--Vapor cooling
