Quick Details

  • Place of Origin: Liaoning, China (Mainland)
  • Brand Name: HUAGUANG
  • Model Number: FU-22S/GU22A
  • Type: Triode Transistor
  • Package Type: Surface Mount
  • material: metal-glass

Packaging & Delivery

Packaging Details Wooden box 62*62*80cm / pcs
Gross weight is about 30 KGS
Delivery Time within 2 days once the payment is confirmed

ISO9001 TY-22A transmitting tube-type electron tubes are glass triodes, with their anodes cooled by cooling manner; Their maximum anode dissipation powers are at 20kW.When at a frequency not higher than 26MHz, their output powers may attain to 30kW; They are mainly applied in industrial high-frequency heating equipments for oscillations or in radio equipments for amplifications.



Glass triode (1-30KW)

Type

FU-22S

Equivalent on abroad

TY-22A

Output power(KW)

30

Cathode

Cathode materials

Thoriated Tungsten

Voltage(V)

8.3

Current(A)

150

Main electric parameters

Amplification factor

49

Inter-electrode Capacitances (PF)

(Cathode earthed)



Filament-Grid

55

Filament-Anode

1.5

Anode-Grid

45

Maximum

Maximum anode dissipation (KW)

20

Maximum grid dissipation (W)

600

Maximum anode DC voltage (KV)

10

Maximum frequency (MHz)

26

Cooling

S

Weight (kg)

5

Additional: The information here may be modified with the products variation.

Cooling: F--Forced air cooling  S--Water cooling  Z--Vapor cooling
